1000 ohm to 8 ohm, Minature audio transformer.
Specifications: • Impedance; 600 ohm to 600 ohm, 1:1 • Core type/size: EI-14 • Pri=55 ohm / Sec= 42 ohm • D.C. resistance tolerance: ±15% • Impedance variation: ±10% @ 1KHz • Insulation: >10MΩ @ 100VDC • Breakdown voltage: 100VAC HIPOT for 1 minute • Maximum output: 75mW • Frequency response: ±3dB, 300Hz-3.4KHz @ 1KHz 0dB • Waxing: vacuum treatment • PC leads are soft metal wire and can be adjusted to fit a variety of applications.
